产品详情
顺络AMCW4532B-2-110T车载电感
顺络AMCW4532B-2-220T电感 汽车电子电感
顺络AMCW4532B-2-510T AMCW4532B-2-101T
| Part Number | Inductance (uH) @100KHz/0.1V | Max. DC Resistance | Max. Rated Current | Max. Rated Voltage | Min. Insulation Resistance | Length×Width | Thickness |
| AMCW4532B-2-110T | 11+50%/-30%/100KHz/0.1V | 0.5 | 360 | 50 | 10 | 4.5×3.2 | 2.55 |
| AMCW4532B-2-220T | 22+50%/-30%/100KHz/0.1V | 0.8 | 310 | 50 | 10 | 4.5×3.2 | 2.55 |
| AMCW4532B-2-510T | 51+50%/-30%/1.0MHz/0.1V | 1 | 230 | 50 | 10 | 4.5×3.2 | 2.55 |
| AMCW4532B-2-101T | 100+50%/-30%/1.0MHz/0.1V | 2 | 200 | 50 | 10 | 4.5×3.2 | 2.55 |
