产品详情

NADWS Series SF6 Trace Moisture Tester NADWS系列SF6微量水份测试仪

产品简介

NADWS系列SF6微量水份测试仪是南澳***开发的现代化、高水平、智能型测量仪器。NADWS系列SF6微水测试仪无论从测量原理、自动化程度、使用的方便性而言都有着同类仪器无法比拟的***性，特别是采用了欧洲标准技术，确保数据准确可靠。NADWS系列SF6微水测试仪测量范围宽、响应时间快、测量周期短，显示直观，操作简便。该仪器适用的领域非常广泛，空气、氮气、惰性气体以及任何不含腐蚀性介质的气体的湿度测量，尤其适合于SF6气体的湿度测量，电力、石化、冶金、环保、科研院所等部门均可采用，有着极高的性价比。

产品别名

智能微水测量仪，微水测量仪，微质量测量仪，微水仪

产品特性

1.快速测量：开机后无须预加热，快速达到露点饱和状态。

2.快速省气：测定时耗气仅2L（101.2kPa）左右。

3.自锁接头：采用德国***自锁接头，***，无漏气。

4.数据存储：采用大容量设计，最多可存储60组测试数据。

5.显示清晰：液晶屏直接显示露点、微水（ppm）、环境温度、环境湿度、时间及日期、电池电量等内容。

6.便携式设计：仪器更轻，携带、使用方便。

7.内置电源：内置可充电电池，一次充足可连续工作8小时。

产品参数

测量范围	-60℃~ +20℃（露点）
测量精度	±2℃（-60℃~ -50℃）
测量精度	±1℃（-49℃~ +20℃）（工作范围）
测量时间	≤3分钟/点
采样流量	300ml/min±20%
显示方式	液晶显示器、中英文界面、带背光
电源	交直两用，充电电池可连续工作8小时
检验方式	开机自校功能
整机重量	3.5kg
整机尺寸	250mm×100mm×300mm (长×宽×高)

Product introduction

NADWS Series SF6 Trace Moisture Tester is a high-level, intelligent measuring instruments. Especially with the technology of European standard, ensure the data accurately and reliably. NADWS Series has large measurement range, fast response time, the short measurement cycle, intuitive display, easy to operate. The instrument is suitable for wide range of areas, air, nitrogen, inert gas, as well as non-corrosive gas medium humidity measurement, especially for humidity measurement of SF6 gas. Highly cost effective makes it widely used in electric power, petrochemical, metallurgy, environmental protection, research institutes and other departments.

Also called name

Smart micro water meter, moisture meter, micro-quality meter, moisture meter

The Characteristics of the products

1. Portable design: lighter, portable, easy to use.

2. Measuring fast: no need to wait, can get the humidity data quickly after the boot.

3. Cost saving: gas consumption only 2L (102kPa) when measurement.

4. self-locking connectors: Germany imported self-locking connectors, safe and reliable, no leaks.

5. Data storage: design of large capacity, can store up to 50 groups of test data.

6. Showing clear: the LCD display directly to the dew point, moisture (ppm), ambient temperature, humidity, time and date, battery and so on.

7.RS232 interface: can be connected with the serial printer for data printing.

8. built-in power supply: Built-in rechargeable lithium battery 4Ah, can continuous work for 10 hours once fully charged.

The parameters of the products

1. Measuring range:-60℃~+20℃(dew point)

2. Accuracy: ±2℃ (-60℃~-50℃)

±1℃ (-49℃~+20℃) (operating range)

3. Measuring time: ≤ 3 minutes each point

4. Sampling flow rate: 300 ml/min±20%

5. Display: LED display, with led back-light, English interface, can design English interface according to customer’s requirement.

6. Power Supply: AC-DC dual-use, rechargeable battery can work continuously for eight hours

7. Terms of inspection: self-calibration function when boot.

8. Weight: 3.5KG

9. Dimension: 250mm*100mm*300mm(L*W*H)

Product information

1, NADWS Series SF6 trace water tester should be placed in a secure location to prevent the break and avoid vigorous shaking.

2, Do not measure corrosive gases.

3, The flow valve should be opened slowly when adjust the gas flow, so that the flow directions at 0.5 liters / minute.

4, Fully charged before use. Access to 220V, no need to open the power switch, the instrument will be charged automatically, usually takes more than 20 hours.
