SJ1000-1M-1T 多模1光口1电口100M光电转换器 光纤收发器
¥1600.00
SJ1000-1S-2T 单模1光口2电口100M光电转换器 光纤收发器
¥1800.00
- 商品
- 详情
Mellanox MCX56***-CDAI ConnectX-5 100GbE QSFP28光纤网卡
- ¥1.45万 30 - 59个
- ¥1.43万 ≥60个
参数
- 处理单元产品特性
- NVIDIA Mellanox英伟达.迈络思品牌
- MCX565A-CDAI型号
北京 海淀区
60天内发货
100个
SJ1000-1M-1T 多模1光口1电口100M光电转换器 光纤收发器
¥1600.00
SJ1000-1S-2T 单模1光口2电口100M光电转换器 光纤收发器
¥1800.00
产品详情
Mellanox MCX56***-CDAI ConnectX-5 100GbE QSFP28光纤网卡Mellanox MCX56***-CDAI_C11 OCP NIC 3.0 CSP M1-Arrow
MCX623102AC-GDAT MCX623102AN-GDAT ConnectX-6 50G网卡MCX623432AC-GDAB MCX623432AN-GDAB ConnectX-6 50G网卡
NVIDIA ConnectX-6 DX Ethernet SmartNIC
ConnectX-6 Dx SmartNIC is the industry&＃39;s most secure and advanced cloud network interface card to accelerate mission-critical data-center applications, such as security, virtualization, SDN/NFV, big data, machine learning, and storage. The SmartNIC delivers the highest return on investment (ROI) of any smart network interface card.
ConnectX-6 Dx is a member of NVIDIA&＃39;s world-class, award-winning ConnectX series of network adapters powered by leading 50 Gb/s (PAM4) and 25/10 Gb/s (NRZ) SerDes technology and novel capabilities that accelerate cloud and data-center payloads.
SmartNIC Portfolio
1/10/25/40/50 Gb/s Ethernet, PAM4/NRZ
Various form factors:
PCIe low-profile
OCP 3.0 Small Form Factor (SFF)
OCP 2.0
Connectivity options:
SFP28 and SFP56
PCIe Gen 4.0 x16 host interface
Multi-host and single-host flavors
Crypto and non-crypto versions
Key Features
Solutions
Up to 50 Gb/s bandwidth
Message rate of up to 215 Mpps
Sub 0.8 usec latency
Flexible programmable pipeline for new network flows
Multi-Host with advanced QoS
ASAP2 - Accelerated Switching and Packet Processing for virtual switches/routers
Overlay tunneling technologies
IPsec and TLS in-line crypto acceleration
Block crypto acceleration for data-at-rest
Hardware Root-of-Trust and secure firmware update
Connection Tracking offload
Advanced RoCE capabilities
Best in class PTP for TSN applications
GPUDirect for GPU-to-GPU communication
Host chaining technology for economical rack design
Platform agnostic: x86, Power, Arm
ODCC compatible
Cloud-native, Web 2.0, hyperscale
Enterprise data-centers
Cyber security
Big data analytics
Scale-out compute and storage infrastructure
Telco and Network Function Virtualization (NFV)
Cloud storage
Machine Learning (ML) & Artificial Intelligence (AI)
Media and Entertainment
MCX623432AS-ADAB ConnectX-6 25GB QSFP28双口IB 光纤网卡MCX65310***-ECAT MCX516A-CCAT MCX621102AN-ADAT MCX623102AN-ADAT MCX556A-EDAT 光纤网卡
MCX623430MS-CDAB ConnectX-6 25GB QSFP28双口IB 光纤网卡MCX623432AS-ADAB ConnectX-6 25GB QSFP28双口IB 光纤网卡MCX65310***-ECAT MCX516A-CCAT MCX621102AN-ADAT MCX623102AN-ADAT MCX556A-EDAT 光纤网卡
MCX631432AN-ADAB ConnectX-6 Lx EN adapter card, 25GbE OCP3.0, w/ Host mgmt , Dual-port SFP28, PCIe 4.0 x8, No Crypto光纤网卡MCX623430MS-CDAB ConnectX-6 25GB QSFP28双口IB 光纤网卡MCX623432AS-ADAB ConnectX-6 25GB QSFP28双口IB 光纤网卡MCX65310***-ECAT MCX516A-CCAT MCX621102AN-ADAT MCX623102AN-ADAT MCX556A-EDAT 光纤网卡
NVIDIA ConnectX-6 Lx Ethernet SmartNIC
Providing up to two ports of 25GbE connectivity, and PCIe Gen 3.0/4.0 x8 host connectivity, ConnectX-6 Lx MCX631102AS-ADAT is a member of NVIDIA&＃39;s world-class, award-winning, ConnectX family of network adapters. Continuing NVIDIA&＃39;s consistent innovation in networking, ConnectX-6 Lx provides agility and efficiency at every scale. ConnectX-6 Lx delivers cutting edge 25GbE performance and security for uncompromising data centers.
SmartNIC Portfolio
10/25 Gb/s Ethernet
Various form factors:
PCIe low-profile
OCP 3.0 Small Form Factor (SFF)
Connectivity options:
SFP28
PCIe Gen 3.0/4.0 x8
Crypto and non-crypto versions
Features & Applications
Line speed message rate of 75Mpps
Advanced RoCE
ASAP2
Accelerated Switching and Packet Processing
IPsec in-line crypto acceleration
Overlay tunneling accelerations
Stateful rule checking for connection tracking
Hardware Root-of-Trust and secure firmware update
Best-in-class PTP performance
ODCC compatible
MCX631432AC-ADAB ellanox ConnectX-6 Lx EN adapter card, 25GbE, Dual-port SFP28,PCIe 4.0 x8迈络思光纤网卡MCX631432AN-ADAB ConnectX-6 Lx EN adapter card, 25GbE OCP3.0, w/ Host mgmt , Dual-port SFP28, PCIe 4.0 x8, No Crypto光纤网卡MCX623430MS-CDAB ConnectX-6 25GB QSFP28双口IB 光纤网卡MCX623432AS-ADAB ConnectX-6 25GB QSFP28双口IB 光纤网卡MCX65310***-ECAT MCX516A-CCAT MCX621102AN-ADAT MCX623102AN-ADAT MCX556A-EDAT 光纤网卡
NVIDIA MBF2H332A-AENOT BlueField-2 SmartNIC P-Series DPU 25GbE Dual-Port SFP56 PCIe Gen4 x8 Crypto Disabled 16GB On-Board DDR 1GbE OOB Management Tall Bracket HHHL（非加密）DPU数据处理单元MCX631432AN-ADAB ellanox ConnectX-6 Lx EN adapter card, 25GbE, Dual-port SFP28,PCIe 4.0 x8迈络思光纤网卡MCX631432AN-ADAB ConnectX-6 Lx EN adapter card, 25GbE OCP3.0, w/ Host mgmt , Dual-port SFP28, PCIe 4.0 x8, No Crypto光纤网卡MCX623430MS-CDAB ConnectX-6 25GB QSFP28双口IB 光纤网卡MCX623432AS-ADAB ConnectX-6 25GB QSFP28双口IB 光纤网卡MCX65310***-ECAT MCX516A-CCAT MCX621102AN-ADAT MCX623102AN-ADAT MCX556A-EDAT 光纤网卡
NVIDIA MBF2H332A-AENOT BlueField-2 SmartNIC （MBF2H332A-AENOT） 技术参数
NVIDIA MBF2H332A-AENOT BlueField-2 SmartNIC P-Series DPU 25GbE Dual-Port SFP56 PCIe Gen4 x8 Crypto Disabled 16GB On-Board DDR 1GbE OOB Management Tall Bracket HHHL（非加密）
Technology :Ethernet
Max Speed :25GbE
Connector Type : QSFP56
Ports : Dual
25GbE双端口SFP56 PCIe Gen4 x8加密禁用16GB板载DDR 1GbE OOB管理高支架HHL
芯片上的数据中心基础设施
英伟达BLUVELD-2数据处理单元（DPU）是一个数据中心基础设施，它为传统的企业、高性能计算（HPC）和现代云工作负载优化，提供了一组广泛的加速软件定义的网络、存储、安全和管理服务。BlueField-2 DPU使企业能够将其IT基础设施转变为进的数据中心，这些数据中心经过加速、完全可编程，并配备零信任安全性，以防止数据泄露和网络攻击。
安全
硬件信任根
正则表达式（RegEx）匹配处理器加速
硬化隔离层
IPsec/TLS和XTS加密
有状态防火墙加速的连接跟踪
存储
GPUDirect存储
通过NVMe快照存储虚拟化实现的弹性块存储
加速器的NVMe
VirtIO-blk加速器
网络
RoCE，零接触RoCE
GPU指令
病毒网络加速器
加速交换和数据包处理（ASAP2）
OVS和OVN加速
| OPN | Marketing Description |
|---|---|
| MCX65110***-EDAT | ConnectX-6 VPI adapter card, 100Gb/s (HDR100, EDR IB and 100GbE, single-port QSFP56, PCIe4.0 x8, tall bracket |
| MCX65310***-HDAT | ConnectX-6 VPI adapter card, HDR IB (200Gb/s) and 200GbE, single-port QSFP56, PCIe4.0 x16, tall bracket |
| ConnectX-6 VPI adapter card, HDR IB (200Gb/s) and 200GbE, dual-port QSFP56, PCIe3.0/4.0 x16, tall bracket | |
| ConnectX-6 VPI adapter card, 100Gb/s (HDR100, EDR IB and 100GbE), single-port QSFP56, PCIe3.0/4.0 x16, tall bracket | |
| ConnectX-6 VPI adapter card, 100Gb/s (HDR100, EDR IB and 100GbE), dual-port QSFP56, PCIe3.0/4.0 x16, tall bracket | |
| MCX68310***N-HDAT | ConnectX-6 DE InfiniBand adapter card, HDR, single-port QSFP, PCIe 3.0/4.0 x16, No Crypto, Tall Bracket |
| MCX65310***-HDAL | ConnectX-6 VPI adapter card, HDR IB (200Gb/s) and 200GbE, single-port QSFP56, PCIe4.0 x16, cold plate for liquid-cooled Intel® Server System D50TNP platforms, tall bracket, ROHS R6 |
| ConnectX-6 VPI adapter card, HDR IB (200Gb/s) and 200GbE, dual-port QSFP56, PCIe4.0 x16, cold plate for liquid-cooled Intel® Server System D50TNP platforms, tall bracket, ROHS R6 | |
| MCX65410***-HCAT | ConnectX-6 VPI adapter card kit, HDR IB (200Gb/s) and 200GbE, single-port QSFP56, Socket Direct 2x PCIe3.0 x16, tall brackets |
ConnectX-6 VPI adapter card, HDR IB (200Gb/s) and 200GbE, dual-port QSFP56, Socket Direct 2x PCIe3.0/4.0x16, tall bracket | |
| ConnectX-6 VPI adapter card, 100Gb/s (HDR100, EDR InfiniBand and 100GbE), dual-port QSFP56, Socket Direct 2x PCIe3.0/4.0 x16, tall bracket | |
| MCX65310***-EFAT | ConnectX-6 VPI adapter card, 100Gb/s (HDR100, EDR IB and 100GbE), single-port QSFP56, PCIe3.0/4.0 Socket Direct 2x8 in a row, tall bracket |
| ConnectX-6 VPI adapter card, 100Gb/s (HDR100, EDR IBand100GbE), dual-port QSFP56, PCIe3.0/4.0 Socket Direct 2x8 in a row, tall bracket |
Part Number | MCX65110***-EDAT |
|---|---|
Form Factor/Dimensions | PCIe Half Height, Half Length / 167.65mm x 68.90mm |
Data Transmission Rate | Ethernet: 10/25/40/50/100 Gb/s |
Network Connector Type | Single-port QSFP56 |
PCIe x8 through Edge Connector | PCIe Gen 3.0 / 4.0 SERDES @ 8.0GT/s / 16.0GT/s |
RoHS | RoHS Compliant |
Adapter IC Part Number | MT28908A0-XCCF-HVM |
Part Number | MCX65310***-ECAT | MCX653106A-ECAT | MCX65310***-HDAT | MCX653106A-HDAT |
|---|---|---|---|---|
Form Factor/Dimensions | PCIe Half Height, Half Length / 167.65mm x 68.90mm | |||
Data Transmission Rate | Ethernet: 10/25/40/50/100 Gb/s | Ethernet: 10/25/40/50/100/200 Gb/s | ||
Network Connector Type | Single-port QSFP56 | Dual-port QSFP56 | Single-port QSFP56 | Dual-port QSFP56 |
PCIe x16 through Edge Connector | PCIe Gen 3.0 / 4.0 SERDES @ 8.0GT/s / 16.0GT/s | |||
RoHS | RoHS Compliant | |||
Adapter IC Part Number | MT28908A0-XCCF-HVM |
Part Number | MCX65310***-HDAL | MCX653106A-HDAL |
|---|---|---|
Form Factor/Dimensions | PCIe Half Height, Half Length / 167.65mm x 68.90mm | |
Data Transmission Rate | Ethernet: 10/25/40/50/100/200 Gb/s | |
Network Connector Type | Single-port QSFP56 | Dual-port QSFP56 |
PCIe x16 through Edge Connector | PCIe Gen 3.0 / 4.0 SERDES @ 8.0GT/s / 16.0GT/s | |
RoHS | RoHS Compliant | |
Adapter IC Part Number | MT28908A0-XCCF-HVM |
Part Number | MCX65410***-HCAT | MCX654106A-HCAT | MCX654106A-ECAT |
|---|---|---|---|
Form Factor/Dimensions | Adapter Card: PCIe Half Height, Half Length / 167.65mm x 68.90mm | ||
Data Transmission Rate | Ethernet: 10/25/40/50/100/200 Gb/s | Ethernet: 10/25/40/50/100 Gb/s | |
Network Connector Type | Single-port QSFP56 | Dual-port QSFP56 | |
PCIe x16 through Edge Connector | PCIe Gen 3.0 / 4.0SERDES@ 8.0GT/s / 16.0GT/s | ||
PCIe x16 through Auxiliary Card | PCIe Gen 3.0SERDES@ 8.0GT/s | ||
RoHS | RoHS Compliant | ||
Adapter IC Part Number | MT28908A0-XCCF-HVM |
Part Number | MCX65310***-EFAT | MCX653106A-EFAT |
|---|---|---|
Form Factor/Dimensions | PCIe Half Height, Half Length / 167.65mm x 68.90mm | |
Data Transmission Rate | Ethernet: 10/25/40/50/100 Gb/s | |
Network Connector Type | Single-port QSFP56 | Dual-port QSFP56 |
PCIe x16 through Edge Connector | PCIe Gen 3.0 / 4.0 SERDES @ 8.0GT/s / 16.0GT/s Socket Direct 2x8 in a row | |
RoHS | RoHS Compliant | |
Adapter IC Part Number | MT28908A0-XCCF-HVM |
NVIDIA.Mellanox迈络思以太网交换机NVIDIA.Mellanox英伟达光纤交换机NVIDIA.Mellanox英伟达.迈络思光纤适配卡HCA卡NVIDIA.Mellanox英伟达.迈络思交换机电源NVIDIA.Mellanox英伟达.迈络思光纤网卡NVIDIA.Mellanox英伟达.迈络思交换机连接线NVIDIA.Mellanox英伟达.迈络思光纤模块 InfiniBand交换机IB线缆NVIDIA英伟达显卡NVIDIA英伟达GPU高速运算卡等整机及配件批发
为您推荐
在线问
产品参数
- 处理单元
- NVIDIA Mellanox英伟达.迈络思
- MCX565A-CDAI
- 2019
- 现货
- 数据处理单元
- 46x16
- 0.18
- 30天以上
- YES
- 全国联保
- YES
