德国UTP 8/ENi-Cl 镍铁焊条
- ¥160.00 ≥20公斤起批
参数
- 德国UTP品牌
- ENi-Cl型号
- 2.5/3.2/4.0焊芯直径
山东 济南
不限
10000公斤
德国克虏度镍基合金焊丝山东总代理
¥5.00
产品详情
德国UTP 8/ENi-Cl 镍铁焊条ｈｔｔｐ：／／ｗｗｗ．ｙａｎｑｉｂｘｇ．ｃｏｍ
是否进口 否 品牌 德国UTP 型号 UTP 8、ENi-Cl
牌号 UTP 8、ENi-Cl 产地 德国 类型 镍及镍合金焊条
材质 镍铁 焊芯直径 2.5-3.2-4.0（mm） 药皮性质 碱性焊条
直径 2.5-3.2-4.0（mm） 长度 350-400（mm） 焊接电流 80-120（A）
电流幅度 80-120（A） 熔点 680 工作温度 常温
适用范围 广泛 德国UTP 8/ENi-Cl 镍铁焊条ｈｔｔｐ：／／ｗｗｗ．ｙａｎｑｉｂｘｇ．ｃｏｍ
备注：一口价为1公斤的价格！20公斤/箱！
德国UTP 8/ENi-Cl 镍铁焊条ｈｔｔｐ：／／ｗｗｗ．ｙａｎｑｉｂｘｇ．ｃｏｍ
UTP 8 cast iron
Classifications graphite-basic coated stick electrode
EN *** 1071 AWS A5.15
E C Ni-Cl 1 E Ni-Cl
Characteristics and field of use
UTP 8 is for cold welding of grey and malleable cast iron, cast steel and for joining these
base metals to steel, copper and copper alloys, especially for repair and maintenance.
UTP 8 has excellent welding properties. The easily controllable flow permits spatterfree
welding in all positions and with minimal amperage. The weld deposit and the transition
zones are filable. No undercutting. Ideally suited for the combined welding with the ferronickel
type UTP 86 FN (buttering with UTP 8 and filling with UTP 86 FN).
Typical analysis in C Ni Fe 1,2 balance 1,0 Mechanical properties of the weld metal Yield strength RP0,2 Hardness MPa HB approx. 220 approx. 180 Welding instruction Depending on the wall thickness, the preparation is made in U- or double U-form. The casting skin has to be removed on both sides of the welding area. Hold the stick electrode vertically with a short arc. Thin passes are buttered, their width not more than twice the diameter of the core wire. To avoid over-heating, the beads should not be longer than 10 times the stick electrode diameter. Remove the slag immediately after welding and then peen the deposit carefully. Reignite on the weld deposit and not on the base metal. Welding positions Current type DC (–) / AC Approvals DB (No. 62.138.01) Form of delivery and recommended welding parameters Electrodes Ø mm x L 2,0 x 300 2,5 x 300 3,2 x 350 4,0 x 350 Amperage 45 – 60 60 – 80 80 – 100 110 – 140 德国UTP 8/ENi-Cl 镍铁焊条ｈｔｔｐ：／／ｗｗｗ．ｙａｎｑｉｂｘｇ．ｃｏｍ
