ADXL203CE滥用事件检测±1.7g±5g或±18g双轴加速度计0.06°倾斜

¥390.00 10 - 99PCS
¥360.00 ≥100PCS

参数

加速度计产品特性
ADI亚德诺品牌
ADXL203CE型号

发货地广东深圳 3天内发货供货总量2000PCS

深圳盛思瑞创科技有限公司: 进入店铺在线咨询

ADIS16477-1BMLZ工业自动125度加速度40g惯性测量单元IMU ¥500.00

ADI 亚德诺 ADXL203CE 加速度传感器 ¥60.00

回收各品牌IC芯片ST/意法 TI/德州 ADI/亚德诺 NXP/恩智浦 MICROCHIP/微芯面议

ADI 亚德诺 ADUM1201BRZ 双通道数字隔离器芯片 iCoupler? ¥8.50

供应ADI传感器 TMP05BKSZ-REEL7 ADI亚德诺欢迎咨询原装 ¥0.10

ADCLK944BCPZ-R7 时钟缓冲区/驱动器 ADI/亚德诺封装QFN16 楠面议

产品详情

ADXL203是一款高精度、低功耗、完整的双轴加速度计，提供经过信号调理的电压输出，所有功能均集成于一个单芯片IC中。ADXL203的满量程加速度测量范围为±1.7 g、±5 g或±18 g。ADXL203既可以测量动态加速度（例如振动），也可以测量静态加速度（例如重力）。
典型本底噪声为110 µg/√Hz，因而在倾斜检测应用中，可以利用窄带宽(<60 Hz)解析1 mg（0.06°倾斜）以下的信号。
用户使用XOUT 和 YOUT引脚上的电容CX和CY 选择该加速度计的带宽。根据应用需要，可以选择0.5 Hz至2.5 kHz范围内的带宽。
ADXL203提供5 mm × 5 mm × 2 mm、8引脚陶瓷LCC封装。
应用
平台稳定/调平
导航
警报器和运动检测器
高精度双轴倾斜检测
振动监测和补偿
滥用事件检测

在单芯片IC上实现高性能双轴加速度计
5 mm × 5 mm × 2 mm LCC封装
分辨率：1 mg (60 Hz)
低功耗：700 µA（典型值，VS = 5 V）
高零g偏置稳定性
高灵敏度精度

温度范围：–40°C至+125°C
X轴和Y轴对齐精度：0.1°（典型值）
利用单个电容调整带宽
单电源供电
抗冲击能力：3500 g
符合RoHS标准
与锡/铅和无铅焊接工艺兼容

产品型号	# of Axes	Accelerometer Range	BW (typ)	Output Type	Sensing Axis	Is (typ)	Vs+ (min)	Vs+ (max)	Package
			Hz			A	V	V
ADXL317	3	16 g	4k	I²C, I2S	X, Y, Z	5m	3	3.6
ADXL1003	1	200 g	15k	Analog	X	1m	3	5.5	32-Lead LFCSP (5mm x 5mm x 1.8mm w/ EP)
ADCMXL1021-1	1	50 g	10k	Digital, SPI	Z	23.9m	3	3.6	14-lead Module with integrated flex connector (27 mm x 23.7 mm x 12.4 mm)
ADXL1005	1	100 g	23k	Analog	X	1m	3	5.25	32-Lead LFCSP (5mm x 5mm x 1.8mm w/ EP)
ADXL1001	1	100 g	11k	Analog	X	1m	3.3	5.25	32-Lead LFCSP (5mm x 5mm x 1.8mm w/ EP)
ADXL1002	1	50 g	11k	Analog	X	1m	3.3	5.25	32-Lead LFCSP (5mm x 5mm x 1.8mm w/ EP)
ADXL251	2	120 g, 240 g, 480 g, 60 g	400	PSI5, SPI	X, Y	6m	3.135	11
ADXL356	3	10 g, 20 g, 40 g	2.4k	Analog	X, Y, Z	150µ	2.25	3.6	14-Lead LCC (6mm x 6mm)
ADXL357	3	10 g, 20 g, 40 g	1k	I²C, SPI	X, Y, Z	200µ	2.25	3.6	14-Lead LCC (6mm x 6mm)
ADXL372	3	200 g	3.2k	I²C, SPI	X, Y, Z	22µ	1.6	3.5	16-Lead LGA (3mm x 3.25mm)
ADXL1004	1	500 g	24k	Analog	X	1m	3.3	5.25	32-Lead LFCSP (5mm x 5mm x 1.8mm w/ EP)
ADXL354	3	2 g, 4 g, 8 g	1.9k	Analog	X, Y, Z	150µ	2.25	3.6	14-Lead LCC (6mm x 6mm)
ADXL355	3	2 g, 4 g, 8 g	1k	I²C, SPI	X, Y, Z	200µ	2.25	3.6	14-Lead LCC (6mm x 6mm)
ADXL151	1	120 g, 240 g, 480 g	400	PSI5	X	5m	4.5	11
ADXL316	3	16 g	1.6k	Analog	X, Y, Z	350µ	1.8	3.6	12-Lead LFCSP (4mm x 4mm w/ EP)
ADXL700	3	14.2 g		SPI	X, Y, Z	5m	3.135	5.25
ADXL363	3	2 g, 4 g, 8 g	200	SPI	X, Y, Z	1.8µ	1.6	3.5	16-Lead LGA (3mm x 3.25mm)
ADXL375	3	200 g	1.6k	I²C, SPI	X, Y, Z	145µ	2	3.6	14-Lead LGA (5mm x 3mm)
ADXL313	3	0.5 g, 1 g, 2 g, 4 g	1.6k	I²C, SPI	X, Y, Z	170µ	2	3.6	32-Lead LFCSP (5mm x 5mm x 1.55mm w/ EP)
ADXL288	2	120 g	408	SPI	X, Y	7m	3.135	5.25	16-Lead SOIC w/ EP
ADXL295	2	120 g	408	SPI	X, Y	7m	3.135	5.25
ADXL344	3	16 g, 2 g, 4 g, 8 g	1.6k	I²C, SPI	X, Y, Z	140µ	1.7	2.75	16-Lead LGA (3mm x 3mm)
ADXL350	3	1 g, 2 g, 4 g, 8 g	1.6k	I²C, SPI	X, Y, Z	166µ	2	3.6	16-Lead LGA_CAV (4mm x 3mm x 1.2mm)
ADXL362	3	2 g, 4 g, 8 g	200	SPI	X, Y, Z	1.8µ	1.6	3.5	16-Lead LGA (3mm x 3.25mm)
ADXL377	3	200 g	1.6k	Analog	X, Y, Z	300µ	1.8	3.6
ADXL343	3	16 g, 2 g, 4 g, 8 g	1.6k	I²C, SPI	X, Y, Z	140µ	2	3.6	14-Lead LGA (5mm x 3mm)
ADXL185B	1	120 g, 240 g, 30 g, 480 g, 60 g	398	PSI5	Z	5m		11
ADXL189B	1	120 g, 240 g, 30 g, 480 g, 60 g	398	PSI5	X	5m		11
ADXL195	1	120 g	408	SPI	X		3.135	5.25	16-Lead SOIC w/ EP
ADXL212	2	2 g	500	PWM	X, Y	700µ	3	5.25	8-Lead LCC
ADIS16210	3	1.7 g	50	SPI	X, Y, Z	18m	3	3.6	15-terminal Module (15mm x15mm x 15mm)
ADXL206	2	5 g	400	Analog	X, Y	700µ	4.75	5.25	8-Lead Side Brazed CerDIP
ADXL312	3	1.5 g, 12 g, 3 g, 6 g	1.6k	I²C, SPI	X, Y, Z	170µ	2	3.6	32-Lead LFCSP (5mm x 5mm x 1.55mm w/ EP)
ADXL337	3	3 g	1.6k	Analog	X, Y, Z	350µ	1.8	3.6
ADXL325	3	6 g	1.6k	Analog	X, Y, Z	350µ	1.8	3.6	16-Lead LFCSP (4mm x 4mm)
ADXL326	3	16 g	1.6k	Analog	X, Y, Z	350µ	1.8	3.6	16-Lead LFCSP (4mm x 4mm)
ADXL327	3	2 g	1.6k	Analog	X, Y, Z	350µ	1.8	3.6	16-Lead LFCSP (4mm x 4mm)
ADXL346	3	16 g, 2 g, 4 g, 8 g	1.6k	I²C, SPI	X, Y, Z	140µ	1.7	2.75	16-Lead LGA (3mm x 3mm)
ADIS16240	3	19 g	1.6k	SPI	X, Y, Z	1m	2.4	3.6
ADXL345	3	16 g, 2 g, 4 g, 8 g	1.6k	I²C, SPI	X, Y, Z	140µ	2	3.6	14-Lead LGA (5mm x 3mm)
ADXL335	3	3 g	1.6k	Analog	X, Y, Z	350µ	1.8	3.6	16-Lead LFCSP (4mm x 4mm w/ EP)
ADIS16209	1	±180°, ±90°	50	SPI	X, Y, Z	14m	3	3.6	16-Lead LGA (9.35mm x 9.2mm)
ADXL180	1	50 g	400	2-wire HV or I	X	7.7m	5	14.5	16-Lead LFCSP (5mm x 5mm w/ EP)
ADIS16203	1	±180°	2.25k	SPI	Z	11m	3	3.6	16-Lead LGA (9.35mm x 9.2mm)
ADIS16006	2	5 g	2.25k	SPI	X, Y	1.4m	3	5.25	12-Lead LGA (7.35mm x 7.2mm)
ADIS16201	2	1.7 g	2.25k	SPI	X, Y	11m	3	3.6	16-Lead LGA (9.35mm x 9.2mm)
ADIS16003	2	1.7 g	2.25k	SPI	X, Y	1.4m	3	5.25	12-Lead LGA (7.35mm x 7.2mm)
ADXL103	1	1.7 g	2.5k	Analog	X	700µ	3	6	8-Lead LCC
ADXL203	2	1.7 g	2.5k	Analog	X, Y	700µ	3	6	8-Lead LCC
ADXL213	2	1.2 g	2.5k	PWM	X, Y	700µ	3	6	8-Lead LCC

产品型号	Accelerometer Range	Special Features	Noise Density (typ)	BW (typ)	Output Type	Sensing Axis	Is (typ)	Vs+ (min)	Vs+ (max)	Package
			g/rtHz	Hz			A	V	V
ADXL317	16 g	3.3 V Supply, A2B Compatible, Active Noise Cancellation, Automotive qualified, Condition Based Monitoring, I2C	55	4k	I²C, I2S	X, Y, Z	5m	3	3.6
ADCMXL1021-1	50 g	Internal FFT Calculation, Serial SPI, Vibration	26µ	10k	Digital, SPI	Z	23.9m	3	3.6	14-lead Module with integrated flex connector (27 mm x 23.7 mm x 12.4 mm)
ADCMXL3021	50 g	Spectral Analysis through Internal FFT, Vibration	26µ	10k	Digital, SPI	X, Y, Z	31m	3	3.6	14-lead Module with integrated flex connector (27 mm x 23.7 mm x 12.4 mm)
ADXL251	120 g, 240 g, 480 g, 60 g	Automotive Safety		400	PSI5, SPI	X, Y	6m	3.135	11
ADXL372	200 g	Concussion Sensing, Shock		3.2k	I²C, SPI	X, Y, Z	22µ	1.6	3.5	16-Lead LGA (3mm x 3.25mm)
ADXL152	120 g, 240 g, 480 g	Automotive Safety		820	PSI5	X	5m	4.5	11	12-Lead LFCSP (4mm x 4mm x 1.45mm w/ EP),12-Lead LFCSP (4mm x 4mm w/ EP)
ADXL151	120 g, 240 g, 480 g	Automotive Safety		400	PSI5	X	5m	4.5	11
ADXL700	14.2 g	Automotive Safety, Inclinometer			SPI	X, Y, Z	5m	3.135	5.25
ADXL363	2 g, 4 g, 8 g	Power Management, Vital Sign Monitor	550µ	200	SPI	X, Y, Z	1.8µ	1.6	3.5	16-Lead LGA (3mm x 3.25mm)
ADXL375	200 g	Concussion Sensing, Shock	5m	1.6k	I²C, SPI	X, Y, Z	145µ	2	3.6	14-Lead LGA (5mm x 3mm)
ADXL288	120 g	Automotive Safety		408	SPI	X, Y	7m	3.135	5.25	16-Lead SOIC w/ EP
ADXL295	120 g	Automotive Safety, Vibration		408	SPI	X, Y	7m	3.135	5.25
ADXL362	2 g, 4 g, 8 g	Power Management, Vital Sign Monitor	175µ	200	SPI	X, Y, Z	1.8µ	1.6	3.5	16-Lead LGA (3mm x 3.25mm)
ADXL377	200 g	Concussion Sensing, Shock	2.7m	1.6k	Analog	X, Y, Z	300µ	1.8	3.6
ADXL185B	120 g, 240 g, 30 g, 480 g, 60 g	Automotive Safety		398	PSI5	Z	5m		11
ADXL189B	120 g, 240 g, 30 g, 480 g, 60 g	Automotive Safety		398	PSI5	X	5m		11
ADXL195	120 g	Automotive Safety, Vibration		408	SPI	X		3.135	5.25	16-Lead SOIC w/ EP
ADIS16210	1.7 g	Inclinometer	190µ	50	SPI	X, Y, Z	18m	3	3.6	15-terminal Module (15mm x15mm x 15mm)
ADXL206	5 g	Inclinometer	110µ	400	Analog	X, Y	700µ	4.75	5.25	8-Lead Side Brazed CerDIP
ADIS16240	19 g	Shock	480µ	1.6k	SPI	X, Y, Z	1m	2.4	3.6
ADIS16209	±180°, ±90°	Inclinometer	190µ	50	SPI	X, Y, Z	14m	3	3.6	16-Lead LGA (9.35mm x 9.2mm)
ADXL180	50 g	Automotive Safety	4m	400	2-wire HV or I	X	7.7m	5	14.5	16-Lead LFCSP (5mm x 5mm w/ EP)
ADIS16203	±180°	Inclinometer		2.25k	SPI	Z	11m	3	3.6	16-Lead LGA (9.35mm x 9.2mm)
ADIS16201	1.7 g	Inclinometer	190µ	2.25k	SPI	X, Y	11m	3	3.6	16-Lead LGA (9.35mm x 9.2mm)
