Features & Benefits
Narrow 30° thread profile minimizes radial expansion and
stress in boss
• Permits use of thinner bosses, which can reduce cycling
times and material usage
• Reduces back-out caused by relaxation
• Increases load-carrying capability through increased
thread engagement
• Can be used in repeat assembly operations
Optimum thread pitch allows deeper thread engagement
• Provides increased pull-out values
• Optimizes non-reversibility
• Balances load ratio between plastic and screw
Recessed thread root allows optimal material flow
• Minimizes installation torque
• Improves clamp load
• Minimizes potential of boss cracking
Round body evenly distributes surface contact between
application and screw
• Improves load ratio
• Reduces high points of stress on the boss
Through hardened to Rc 33-39
