BECKHOFF倍福EL3433PLC可编程控制器哪有卖
¥395.00
德国BECKHOFF倍福模块 EL3423 EL3433 端子模块
¥5800.00
- 商品
- 详情
参数
- 否是否进口
- 德国产地
- 否加工定制
上海 青浦区
1天内发货
11只
BECKHOFF倍福EL3433PLC可编程控制器哪有卖
¥395.00
德国BECKHOFF倍福模块 EL3423 EL3433 端子模块
¥5800.00
产品详情
倍福EL3433 BECKHOFF倍福 端子模块EL3433倍福模块***现货倍福EL3433 BECKHOFF倍福 端子模块EL3433倍福模块***现货倍福EL3433 BECKHOFF倍福 端子模块EL3433倍福模块***现货
| EL3413 |
| EL3413-0120 |
| EL3413-0001 |
| EL3433 |
| EL3602 |
| ES3602 |
| EL3602-0002 |
| EL3602-0010 |
| EL3602-0020 |
| EL3612 |
| ES3612 |
| EL3612-0020 |
| EL3632 |
| EL3632-0020 |
| EL3681 |
| ES3681 |
| EL3681-0020 |
| EL3692 |
| EL3692-0020 |
| EL3702 |
| ES3702 |
| EL3742 |
| ES3742 |
| EL3773 |
| EL4001 |
| ES4001 |
| EL4002 |
| ES4002 |
| EL4004 |
| ES4004 |
| EL4008 |
| ES4008 |
| EL4011 |
| ES4011 |
| EL4012 |
| ES4012 |
| EL4014 |
| ES4014 |
| EL4018 |
EL3433 | 3-phase power measurement terminal 500 V AC, 10 A倍福EL3433 BECKHOFF倍福 端子模块EL3433倍福模块***现货
The EL3433 EtherCAT power measurement terminal is a further development of the EL3403. Currents of up to 10 A can be directly measured with the internal current transformers. This way, there are no additional costs for external current transformers. The external bridges 5 & 1&＃39;, 6 & 2&＃39; and 7 & 3&＃39; are already pre-wired. As a result, it is possible to directly connect the supply voltage (5&＃39;, 6&＃39; and 7&＃39;) and the consumer (1, 2 and 3). The EL3433 can deal with simple grid analysis up to the 21st harmonic analysis. Like all measured terminal data, the harmonic content can be read via the process data.
The EL3433 power measurement terminal has neutral conductor current measurement as standard since the 3rd quarter of 2015. At no additional cost to the end user, the terminal features a shunt between pin 4 and pin 8, in order to enable direct neutral conductor analysis.
| Technical data | EL3433 |
|---|---|
| Number of inputs | 4 x current, 3 x voltage |
| Technology | 3-phase power measurement for alternating voltages |
| Oversampling factor | – |
| Distributed clocks | – |
| Conversion time | mains-synchronous |
| Measured values | current (I1, I2, I3, In), voltage, effective power, reactive power, apparent power, energy, cos φ, frequency, harmonic |
| Measuring voltage | max. 500 V AC 3~ (ULX-N: max. 288 V AC) |
| Measuring current | max. 10 A (AC) |
| Resolution | 1 μA, 0.1 mV, 10 mW |
| Measuring error | 0.5 % relative to full scale value (U/I), 1 % calculated value |
| Electrical ***lation | 4500 V |
| Current consumption power contacts | – |
| Current consumption E-bus | typ. 200 mA |
| Special features | direct current measurement, current measurement,harmonic analysis, single-phase operation also possible |
| Weight | approx. 100 g |
| Operating/storage temperature | -25…+60 °C/-40…+85 °C |
| Relative humidity | 95 %, no condensation |
| Vibration/shock resistance | conforms to EN 60068-2-6/EN 60068-2-27 |
| EMC immunity/emission | conforms to EN 61000-6-2/EN 61000-6-4 |
| Protect. class/installation pos. | IP 20/variable |
| Approvals | CE, UL |
倍福EL3433 BECKHOFF数字量端子模块***现货
倍福EL3433 BECKHOFF数字量端子模块***现货脉波列+方向讯号 1→正转脉波列+反转脉波列 0,2→AB 相 0→有效 1→无效 设定要反馈到控制器的编码器每圈所输出的脉冲个数 0→B 相不反 1→B 相反 (此值根据实际情况计算所得) (此值根据实际情况计算所得) (此值根据实际情况计算所得)
Pr43 Pr44 Pr46 Pr48 Pr4A Pr4B Pr10 Pr11 Pr12 Pr21 Pr22
1
*50 *60 *15 0
1/S（此值先为出厂值） HZ（此值先为出厂值） ms（此值先为出厂值） 0→不用 1→使用(很少起伏) 2→使用(起伏较慢) 3→使用(快) 设定用于实时自动增益调整的机械刚性调用
33
SYNTEC 伺服连接与设定手册 3 松下 A5：
34
SYNTEC 伺服连接与设定手册
参数仅供参考
参数 Pr0.00 名称 旋转方向设定 参数范围 0～1 设定值 1 参数意义 0：正向指令时，电机旋转方向 为CW方向 1：正向指令时，电机旋转方向 为CCW方向 0：位置 1：速度 2：转矩 0：无效 1：标准 此值根据实际情况设定 此值根据实际情况设定 0 0：光电耦合器输入 1：长线驱动器专用输入 如果出现转动手轮脉冲发出在 向上增加，回收在减小的情况 要调整此参数 0,2：AB相 1：正负相脉冲 3：脉冲序列+符号 设为 0 时， Pr0.09 ， Pr0.10 参数 有效 此值根据实际情况设定 此值根据实际情况设定 1~262144 0~262144 2500 0 此值根据实际情况设定 此值根据实际情况设定倍福EL3433 BECKHOFF数字量端子模块***现货倍福EL3433 BECKHOFF倍福 端子模块EL3433倍福模块***现货
