IC200CHS001
面议
IC200CHS002
面议
IC200CHS003
面议
IC200CHS014
面议
IC200CHS022
面议
IC200CHS025
面议
IC200ALG630
IC200ALG630
模拟输入12位电压
电流4通道IC200ALG263(6)模拟输入15位电压15
渠道
IC200ALG240模拟输入16位电压/
电流隔离8通道IC200ALG264(6)模拟输入15位电流15
渠道
IC200ALG260模拟输入12位电压/
电流8通道IC200ALG620模拟输入16位RTD 4
渠道
IC200ALG261(6)模拟输入15位差分
电压8通道IC200ALG630模拟输入16位
热电偶7通道
IC200ALG262(6)模拟输入15bit差分
当前8通道
模拟输出
模块介绍(1)IC200ALG320模拟输入12bit电压/
电流4通道IC200ALG326(6)模拟输出13位电流8
渠道
IC200ALG321模拟输出12位电压
0- 10v 4通道IC200ALG327(6)模拟输出13位电压12
渠道
IC200ALG322模拟输出12位电压±10
V 4通道IC200ALG331模拟输出16位电压/
电流隔离4通道
IC200ALG325(6)模拟输出13位电压
渠道
混合模拟
模块介绍(1)IC200ALG430模拟混合12位电流
输入/ 2输出通道IC200ALG432模拟混合12位电压±10
V 4输入/ 2输出通道
IC200ALG431模拟混合12位电压0-10
V 4输入/ 2输出通道
I/O载体IC200CHS001屏障水平风格IC200CHS025弹簧钳垂直风格
IC200CHS011非集成屏障式
IC200CHS003(4)连接器垂直式IC200CHS012非集成盒式
IC200CHS014集成箱式热电偶
补偿
IC200CHS022盒垂直样式
I / O中介
底座IC200CHS101非一体机箱样式IC200CHS112非一体机箱样式
IC200CHS102非集成盒型IC200CHS211非集成盒型
IC200CHS111非集成盒型IC200CHS212非集成盒型
远程I/O单元IC200DBI001(2)远程I/O DeviceNet网络
接口单元IC200GBI001远程I/O天才网络
接口单元
IC200EBI001(5)远程I/O以太网
接口单元IC200PBI001远程I/O Profibus-DP网络
接口单元
PROFINET NIUS IC200PNS001 2xRJ45铜以太网
连接器IC200PNS002 2xST光纤以太网连接器
网络
接口
模块(3)
PLC网络通讯
Profibus-DP从站IC200CHS006本地通信载波
PLC网络通讯
DeviceNet (Master/Slave) IC200CMM020
天才网络接口作品
用于GBI或PNS模块
Modbus Master Serial Module
(1个RS-485接口)
控制器IC200CPU001
CPU 42 kB可配置
内存，两个串行端口(RS-232)
和rs - 485)
IC200CPUE05
可配置用户内存，1个
10MBps以太网(RJ45)和2个
串口(RS-232和RS-485)
为了监测该模块的状态，提供了诊断功能和板载LED灯。可以提供范围状态、现场断电、NVRAM故障、断线等诊断报告。LED灯指示模块和电源状态。
IC200ALG240宽4.3英寸，即110毫米;2.63英寸高，或66.8毫米;深1.956英寸，即50毫米。注:这些尺寸不包括载体或配合连接器的高度。该模块采用5V和3.3V连接背板，为设备供电。5V背板的电流消耗可达15毫安，3.3V背板的电流消耗可达120毫安。
技术规格
不。输入:8个隔离
电压范围:直流-10 ~ +10伏
电流范围:4 - 20毫安
更新速度:20毫秒
输入滤波器响应:无
功耗:15ma从+5V总线
Maximum versatility is the guiding principle
behind VersaMax from Emerson. This compact,
extremely affordable, control solution can be
used as a compact PLC, distributed I/O, or
distributed control. With its modular and
scalable architecture, intuitive features and ease
of use, this innovative control family can save
machine builders and end users considerable
time and money.
Offering Big PLC Power
in a Small Package
VersaMax Modular CPUs supply a number of features usually
found only in PLCs with larger footprints, including up to
128kB of memory for application programs, floating point
math, real-time clock, subroutines, PID control, flash memory,
and bumpless program store. The serial ports support serial
read/write and Modbus master/slave communications.
An Abundance of Useful I/O Options
Emerson offers a broad range of discrete, analog, mixed, and
specialty I/O modules. These modules can be freely combined
to create stand-alone I/O stations with up to 256 I/O points
and expanded I/O systems with up to 2048 I/O points.
The Perfect Match for Today’s
Open Systems
VersaMax gives you the freedom to connect to a wide variety
of host controllers, including PLC, DCS and PC-based control
systems by way of PROFINET (remote I/O only), Modbus/TCP,
and other Ethernet networks as well as Genius, DeviceNet,
Profibus-DP. VersaMax also fully supports the power and open
architecture of Emerson’s PC Control solutions.
The Ultimate in Cost-effective
Control and I/O
With intuitive diagnostics, hot insertion of modules and quick
connect wiring, VersaMax extends uptime, reduces engineering and training needs, and dramatically reduces project
IC200ALG240模拟输入模块属于GE Fanuc Versamax系列I/O模块。它有8个模拟输入，16位分辨率，在25摄氏度下+/-0.1%精度，1500伏交流隔离电压。该模块可以自由组合以构建独立的I/O站。它提供热插入功能和快速，经济高效的布线系统。它不需要任何特殊的工具来提取或安装。IC200ALG240模拟输入模块还提供了一个50或60赫兹频率可编程陷波的数字场输入滤波器。它的诊断设施包括高/低限制、开路、现场电源丢失和非易失性存储器故障诊断。
IC200ALG240模拟输入模块在电流模式下需要单独的电源隔离输入。它有2个指示led，即“FLD PWR”和“OK”led。“FLD PWR”LED向模拟场侧电路显示背板或场电源的存在。绿色“OK”指示灯表示模块的状态。系统CPU或NIU从模拟输入模块接收8个字的模拟输入数据。它没有热降额。IC200ALG240输入模块的主要特点包括16位转换器分辨率，高精度工厂校准和断线检测。模块操作可通过A1 ~ A18端子连接24伏直流电源实现。它的默认配置适合在许多应用程序中使用。但是，在连接到I/O站或Versamax PLC系统之前，必须对其进行软件配置。它是在工厂校准的。
Made by GE Intelligent Platforms, the IC200ALG240 is a VersaMax Analog Input Module. This module is capable of processing input signals from a maximum of eight analog devices and providing data output at a resolution of 16 bits. The IC200ALG240 has two modes of operation: voltage mode and current mode. In voltage mode, the input range is 1 to 20 milliamps. In current mode, the input range is +/- 10 volts.
This module has eight ***lated input channels, each of which has a current range of 4 to 20 milliamps. Additional features of this device include the ability to detect open wires, a converter resolution of 16 bits, and precise factory calibration. Certain features of the IC200ALG240 can also be configured and altered via software, such as changing alarm levels for individual channels, changing the default values for individual channels, and scaling individual channels. The update rate for channel data is 20mS at 50Hz filter frequency and 16.7mS at 60Hz filter frequency.
To monitor status for this module, diagnostic features and on-board LED lights are provided. Diagnostic reports on range status, field power loss, NVRAM faults, the presence of open wires, and more are available. The LED lights indicate module and power status.
The IC200ALG240 is 4.3 inches wide, or 110mm; 2.63 inches tall, or 66.8mm; and 1.956 inches deep, or 50mm. Note: These dimensions do not include the carrier or mating connector height. A 5V and a 3.3V connection backplane are used for this module, through which power is provided to the device. The 5V backplane consumes up to 15 milliamps of current, and the 3.3V backplane consumes up to 120 milliamps of current.
Technical Specifications
No. of Inputs: 8 ***lated
Voltage Range: -10 to +10 volts DC
Current Range: 4 - 20 mA
Update Rate: 20 ms
Input Filter Response: N/A
Power Consumption: 15 mA from +5V bus
The IC200ALG240 Analog Input Module belongs to the GE Fanuc Versamax family of I/O modules. It has 8 analog inputs, 16 bits of resolution, +/-0.1% accuracy at 25 degrees Celsius, and 1500 Volts AC of ***lation voltage. This module can be freely combined to build a standalone I/O station. It offers hot insertion capabilities and a quick, cost-effective wiring system. It does not require any special tools for extraction or installation. The IC200ALG240 Analog Input Module also offers a digital field input filter with programmable notches at 50 or 60 Hertz frequency. Its diagnostic facilities include high/low limit, open wire, loss of field power supply, and non-volatile memory fault diagnostics.
The IC200ALG240 Analog Input Module requires a separate power supply for ***lated inputs in the current mode. It has 2 indicator LEDs that are the “FLD PWR” and “OK” LEDs. The “FLD PWR” LED shows the presence of backplane or field power to the analog field-side circuits. The green “OK” LED indicates the module’s status. The system CPU or NIU receives 8 words of analog input data from this analog input module. It does not have thermal derating. The main features of the IC200ALG240 Input Module include 16-bit converter resolution, high accuracy factory calibration, and open wire detection. The module operation can be done by connecting a 24 Volts DC power supply to terminals A1 to A18. Its default configuration is suitable to use in many applications. However, it must be software-configured before connecting to the I/O station or Versamax PLC system. It is calibrated at the factory.
