LARTON CE/60玻矿增强低翘曲PPS
¥71.00
LARTON G/40耐化学40%GF增强PPS
¥80.00
40%GF耐热耐化学PPS LARTON G/40 I6
¥82.00
LARTON GCE/600玻矿增强耐热PPS
¥70.00
65%玻矿增强PPS LARTON GCE/650
¥71.00
LARTON GK/400导电40%玻纤碳纤PPS
¥95.00
LARIL 13-V1KC低翘曲矿物增强PPO
Density | 1.37 | g/cm | *** 1183 |
Molding Shrinkage3 | *** 294-4 | ||
Across Flow : 2.00 mm | 0.40 to 0.70 | % | |
Flow : 2.00 mm | 0.40 to 0.70 | % | |
Water Absorption(24 hr, 23°C) | 0.030 | % | *** 62 |
| Mechanical | Nominal Value | Unit | Test Method |
Tensile Modulus | *** 527-1/1 | ||
23°C | 4960 | MPa | |
60°C | 4270 | MPa | |
91°C | 3590 | MPa | |
121°C | 3170 | MPa |
Charpy Notched Impact Strength(23°C) | 4.9 | kJ/m | *** 179/1eA |
Charpy Unnotched Impact Strength(23°C) | 15 | kJ/m | *** 179/1eU |
| Thermal | Nominal Value | Unit | Test Method |
Deflection Temperature Under Load | |||
0.45 MPa, Unannealed | 140 | °C | *** 75-2/B |
1.8 MPa, Unannealed | 135 | °C | *** 75-2/A |
Continuous Use Temperature4 | 105 | °C | ASTM E1641/E1877 |
Vicat Softening Temperature | 145 | °C | *** 306/B50 |
CLTE - Flow(30 to 100°C) | 3.0E-5 | cm/cm/°C | *** 11359-2 |
| Electrical | Nominal Value | Unit | Test Method |
Surface Resistivity | 1.0E+12 | ohms | ASTM D257 |
Comparative Tracking Index5(Solution A) | 250 | V | IEC 60112 |
| Flammability | Nominal Value | Unit | Test Method |
Flame Rating | UL 94 | ||
1.5 mm | V-1 | ||
3.0 mm | V-1 |
