加玻纤30%聚苯硫醚 Ryton XE5430BL PPS XE5430NA 美国苏威

¥35.00 ≥1千克起批

参数

否是否进口
美国产地
美国苏威厂家(产地)

发货地广东东莞 1天内发货供货总量18000千克

东莞市樟木头双浩塑胶原料经营部: 进入店铺在线咨询

30%玻纤高耐热PPS RYTON XE5430BL ¥59.50

Ryton PPS雪佛龙菲利普斯XE5515BL 耐化学高强度黑色 ¥50.70

Ryton XE3500BL 聚苯硫醚合金料 ¥65.00

索尔维/苏威Solvay PPS Ryton XE4050BL 高冲击高韧性热稳定聚苯硫醚 ¥62.00

长期提供原料PPS 美国雪佛龙菲利普 Ryton XE5515BL 面议

索尔维RytonXE3500BL高强度耐化学品性能良好韧性良好延展性PPS ¥69.00

产品详情

Physical Properties	Metric	English	Comments

Density	1.52 g/cc	0.0549 lb/in³	Method A; *** 1183
Water Absorption	0.020 % @Time 86400 sec	0.020 % @Time 24.0 hour	ASTM D570

Mechanical Properties	Metric	English	Comments
Tensile Strength	150 MPa	21800 psi	ASTM D638
Elongation at Break	2.1 %	2.1 %	ASTM D638
Flexural Strength	220 MPa	31900 psi	ASTM D790
Flexural Modulus	9.00 GPa	1310 ksi	*** 178
Compressive Strength	215 MPa	31200 psi	ASTM D695
Izod Impact, Notched (***)	11.0 kJ/m²	5.23 ft-lb/in²	Notch A; *** 180
Izod Impact, Unnotched (***)	55.0 kJ/m²	26.2 ft-lb/in²	*** 180

Electrical Properties	Metric	English	Comments
Volume Resistivity	1.00e+16 ohm-cm	1.00e+16 ohm-cm	ASTM D257
Dielectric Constant	3.7 @Frequency 1000 Hz	3.7 @Frequency 1000 Hz	ASTM D150
	3.7 @Frequency 1.00e+6 Hz	3.7 @Frequency 1.00e+6 Hz	ASTM D150
Dielectric Strength	20.0 kV/mm	508 kV/in	ASTM D149
Dissipation Factor	0.0020 @Frequency 1000 Hz	0.0020 @Frequency 1000 Hz	ASTM D150
	0.0020 @Frequency 1.00e+6 Hz	0.0020 @Frequency 1.00e+6 Hz	ASTM D150
Arc Resistance	125 sec	125 sec	ASTM D495
Comparative Tracking Index	150 V	150 V	UL 746

Thermal Properties	Metric	English	Comments
CTE, linear, Parallel to Flow	10.0 µm/m-°C @Temperature 100 - 200 °C	5.56 µin/in-°F @Temperature 212 - 392 °F	*** 11359-2
	20.0 µm/m-°C @Temperature -50.0 - 50.0 °C	11.1 µin/in-°F @Temperature -58.0 - 122 °F	*** 11359-2
CTE, linear, Transverse to Flow	55.0 µm/m-°C @Temperature -50.0 - 50.0 °C	30.6 µin/in-°F @Temperature -58.0 - 122 °F	*** 11359-2
	90.0 µm/m-°C @Temperature 100 - 200 °C	50.0 µin/in-°F @Temperature 212 - 392 °F	*** 11359-2
Thermal Conductivity	0.270 W/m-K	1.87 BTU-in/hr-ft²-°F	*** 8302
Flammability, UL94	V-0 @Thickness 1.60 mm	V-0 @Thickness 0.0630 in
